PD195Z-E33 DC multi-circuit power meter

The Product Name:
PD195Z-E33 DC multi-circuit power meter
The Product Type:
Multi-circuit monitoring system
Inquiry:
Corresponding field:
smart building smart metering smart building energy solutions device-to-infrastructure


Display mode

LCD



Accuracy

V/A
0.2%
P/Q/S/PF
0.5%
F
±0.01Hz
±KWh
Class 0.5s
±Kvarh
Class 2



Voltage Input

Rated value
AC100V   AC380V
Overload
Continuous:1.2Vn  Instantaneous:2Vn/10s
Burden
≤0.1VA(per phase)
Impedance
≥1.7MΩ
Frequency
45Hz~65Hz


Current Input

Rated value
AC1A  AC5A
Overload
Continuous:1.2In  Instantaneous:2In/5s
Burden
≤0.2VA(per phase)
Impedance
≤20MΩ
Residual Current Input

AC 1mA


Auxiliary Power Supply

Working Range
AC 80~270V 50/60HZ ,DC 100~350V
Consumption
≤5VA



Communication Port


RS485,Modbus-RTU ,2-wire,up to 9600bps
LORA EC2 module470MHZ
GPRS EC4 module850/900/1800/1900MHZ
NB-IOT EC6 moduleBand 3/5/8
Energy Pulse Output

1 photocoupler output,pulse width (80±20%)ms


Optional Module(EK1)

Digital Inputs
Dry digital inputs,Isolation:≥2kvac
Relay outputs
Contact rated at AC 250/5A or DC 30V/5A



Environment Conditions

Operating temperature
-25℃~70℃
Storage temperature
-30℃~80℃
Relative humidity
≤93%
Altitude
≤2500m
Insulation

≥2kvac
