DTSF1946-4M-01 EV charger 3 phase AC energy meter

The Product Name:
DTSF1946-4M-01 EV charger 3 phase AC energy meter
The Product Type:
EV charger metering
Inquiry:
Corresponding field:
EV charger Wall box Charging pipe Charge station



Product Name: DTSF1946-4M-01 EV charger 3 phase AC energy meter

Elecnova DTS1946-4M-01 3 phase energy meter is a core component to the electric vehicle charger power measuring and fiscal billing. It’s MID Class B certified available up to 63A current input direct connection.The DTS1946-4M-01 available for the extreme ambient temperature rang at -40℃~+70℃. The measuring data could be integrated with the management system of the EV charger by Modbus RTU communication protocol. It’s widely use for the AC wallbox and charging pipes.




Characteristics

MID Certified

63A direct connection

l I/U/P/F/EP

-40℃~+70℃ working temperature

Modbus RTU communication protocol access

Baud rate: 1200~9600 bps

Energy pulse


EMC Standard Compliance

Electrostatic discharge immunity :                                                                 IEC61000-4-2-III

RF electromagnetic field radiation immunity                                                  IEC61000-4-3-III

Electrical fast transient burst immunity                                                           IEC61000-4-4-IV

Shock(Surge) Immunity                                                                                  IEC61000-4-5-IV

Immunity to conducted disturbances, induced by radio-frequencycy fields    IEC61000-4-6-III

Power frequency magnetic field immunity                                                      IEC61000-4-8-III

Voltage dips and short interruptions immunity                                                IEC61000-4-11-III
